ANTISTATIC PVC (GRID) SIZE 0.3*1370*30 M
ESD curtain or antistatic curtain is soft, transparent, clean, antistatic, shielding heat and noise, free for operator and cart passing. It is suited for electronics, food, pharmaceutical, refrigeration industry. Easy to install and replace, can be cleaned into shining as new with neutral detergent. Good for using as a barrier wall or protecting window curtain in static charge critical environment. Antistatic PVC curtain is composed of antistatic PVC sheet, easy to overhang which helps it to protect EPA area.
Specification :
- Size : 0.3 x 1370 x 30m
- 30 m / roll
- Anti static PVC curtain
- Resistant to pressure and shock
- Optional colors: transparent, transparent net, black net, black, anti-ultraviolet radiation grid
- Anti-static, insulation, heat insulation, dust-proof
| Anti – Static PVC Grid | |||
| Surface | Black | est Method | |
| Surface Resistivity | 10’~10’Ohm/Sq.m | 10’~10’Ohm/Sq.m | ASTM D-257 |
| Electrostatic Voltage | 50 V I | 100 V I | Electro Static
Field Meter |
| Electrostatic Decay | 0.5 sec I | 0.5 sec I | MIL-B-81705C,
500-V→500V |
| Flame Retardant | PASS | JIS A-1322 | |
| Tensile Strength | Length/MD
Width/TD |
1.8kg/mm² | ASTM D-822 |
| 100% Modulus | Length/MD
Width/TD |
1.1kg/mm²
1.8kg/mm² |
ASTM D-822 |
| Elangation |
Length/MD Width/TD |
170%
210% |
ASTM D-822 |
| Heat Shrinkage | 60°C x 30min | 1% I
5% I |
|
| Size | Thickness
Width Roll |
0.3\0.5\1.02.0mm
1.370mm 30m/Roll |
|
